MINI-SYS-PS-100-240AC/24DC/1.5
Connection, network forms 100...240 V AC networks
TN-S
L
N
PE
TN-C
L
PEN
TT
L
N
iT
L1
L2
L3
L N
MINI
+ -
L N
MINI
+ -
L N
MINI
+ -
L N
MINI
+ -
The 100...240 V AC connection is made using the L and N
screw connections.
The device can be connected to 1-phase AC systems or to
two of the phase conductors of three-phase systems (TN, TT
For operation on two of the phase conductors
of a three-phase system, an isolating facility for
all poles must be provided.
or IT networks in acc. with VDE 0100-300/IEC 60364-3) with
nominal voltages of 100 V AC ...240 V AC.
Input
Protection of the primary side
The device must be installed in acc. with the regulations as
in EN 60950. It must be possible to disconnect the device
1
33
34
L
NC
N
71
72
63
64
using a suitable isolating facility outside the power supply.
The primary side line protection, for example, is suitable. For
device protection, there is an internal fuse. Additional device
protection is not necessary.
Recommended backup fuse for mains protection
Power circuit-breaker 6 A, 10 A or 16 A, characteristic B (or
identical function).
If an internal fuse is triggered, there is most
probably a malfunction in the device. In this
case, the device must be inspected in the
factory!
102050_01_en
